STANDARD FEATURES:
- AISI 304 stainless steel frame on wheels
- PVC belt
- AISI 304 stainless steel collecting basin and scraper
- Grape separation channels
- Electric panel 400/3/50 complete of electronic speed variator
OPTIONALS:
- AISI 304 stainless steel hopper for bins unloading
- Box support
| NC 2500 | NC 3000 | NC 3500 | NC 4000 | ||
|---|---|---|---|---|---|
| Installed power | kw | 0.75 | 0.75 | 0.75 | 0.75 |
| Hourly output | Ton/h | 2/10 | 2/10 | 2/10 | 2/10 |
| Outlet height | mm | 550-750 | 550-750 | 550-750 | 550-750 |
| Top height | mm | 850-1050 | 850-1050 | 850-1050 | 850-1050 |
| Belt width | mm | 800 | 800 | 800 | 800 |
| Belt lenght | mm | 2500 | 3000 | 3500 | 4000 |
| Dimensions | mm | 2700x1200x1150 | 3200x1200x1150 | 3700x1200x1150 | 4200x1200x1150 |
| Weight | kg | 250 | 270 | 290 | 310 |
